1. Challenges in Oilfield Water Treatment

During the primary separation of hydrocarbon fluids in oil production, demulsification and phase separation often fail to completely remove hydrocarbons from the water phase, resulting in water that does not meet discharge standards. Depending on the region, the maximum allowable residual oil concentration in treated water can range from 40 ppm to as low as 10 ppm. Environmental regulations may further tighten these limits, particularly in offshore operations.

To meet these requirements, separation systems are typically equipped with additional wastewater treatment equipment, such as hydrocyclones, flotation tanks, filters, and centrifuges, to further remove oil droplets from water. The performance of these systems can be significantly enhanced by using chemical flocculants, which act as both oil-water separators (removing oil) and water clarifiers (improving water quality).

2. Mechanisms of Emulsion Stabilization and How Water Clarifiers Work

Emulsified oil droplets that escape primary separation resist further coalescence due to two key mechanisms. First, the droplets carry a negative surface charge, causing mutual repulsion that prevents aggregation. When fluids are processed, pressure reduction increases water pH, leading to the deprotonation of fatty acids and naphthenic acids in crude oil. This forms negatively charged salts, further enhancing droplet repulsion. Second, in high-salinity produced water, fatty acids and naphthenic acids react with calcium ions to form calcium soaps, which adsorb at the oil-water interface and hinder coalescence. Additionally, organic and inorganic solid particles can attach to the interface, forming a protective film that prevents droplet contact and aggregation. If droplets are small enough, Brownian motion keeps them stable for extended periods.

To effectively remove oil, polyelectrolytes are used as flocculants. These chemicals neutralize the negative charges on oil droplets, promoting flocculation into larger clusters that are more easily removed by physical separation equipment. An ideal flocculant should function effectively in high-salinity produced water, neutralizing charges and acting as a "bridge" to connect droplets, facilitating aggregation and final separation.

3. UNP Chemicals’ WAMET™ & DEMET™ Water Clarifiers: Key Features and Advantages

UNP Chemicals' WAMET™ and DEMET™ water clarifiers are specially designed for oilfield water treatment, effectively addressing the challenges mentioned above. These products feature advanced formulations that rapidly neutralize negative charges on emulsified droplets, break emulsions, and promote the flocculation and settling of oil droplets and solid particles.

Key Benefits:

• High Salinity & Hardness Tolerance – Performs effectively in complex water conditions, including high TDS and calcium/magnesium-rich environments.

• Fast Charge Neutralization & Flocculation – Enhances separation efficiency in hydrocyclones, centrifuges, and flotation units.

• Compliance with Strict Discharge Standards – Reduces residual oil content to meet regulatory limits (e.g., <10 ppm).

• Cost-Effective Operation – Lowers energy consumption compared to deep treatment methods like activated carbon or membrane filtration.

4. Application Scenarios and Economic Benefits in Oilfield Operations

Water clarifiers play a crucial role in optimizing oilfield water treatment processes, including:

• Produced Water Treatment – Ensures treated water meets discharge or reinjection standards, avoiding environmental penalties.

• Equipment Protection – Reduces fouling in hydrocyclones, filters, and membranes, extending equipment lifespan and minimizing maintenance.

• Operational Cost Savings – Replaces energy-intensive treatment methods, cutting processing costs by up to 30%.

Case Example: In an offshore oilfield, the use of WAMET 34 improved oil removal efficiency from 75% to 98%, saving over $200,000 annually in wastewater treatment expenses.

5. Future Trends: Smart Formulations and Nanotechnology for Next-Gen Clarifiers

As environmental regulations tighten and oilfield conditions become more challenging, future developments in water clarifiers will focus on:

• Smart Responsive Formulations – Adjust charge density and molecular weight in real time based on water chemistry (pH, salinity, temperature).

• Nanomaterial-Enhanced Clarifiers – Incorporation of nano-silica or carbon nanotubes to improve flocculation speed and efficiency, even at ultra-low oil concentrations (<1 ppm).

• Biodegradable Solutions – Eco-friendly clarifiers that degrade naturally, aligning with "green oilfield" sustainability goals.

Conclusion

UNP Chemicals’ WAMET™ and DEMET™ water clarifiers provide a reliable, high-performance solution for oilfield water treatment, ensuring compliance with environmental standards while optimizing operational efficiency. With ongoing advancements in smart and nano-enhanced formulations, these products will continue to play a vital role in sustainable oil and gas production.

---

Technical Specifications (Reference Table from Image):

For more details on product selection and application, consult UNP Chemicals’ technical support team.
